Nikon Coolscan 5000ED

Film type: 35mm (135)

Reading resolution: 4,000 dpi

Film adapters and holders:

• Slide Strip Adapter SA-21 (2 to 6 Frames)
• Slide Mount Adapter MA-21 (1 Frame)
• Slide Strip Adapter SA-30 (2 to 40 Frames) w/ Film drum ***
• Strip Film Holder FH-3 (1 to 6 Frames) ***
• IX240 Film Adapter IA-20 (15-25-40 Frames) ***
• Slide Feeder SF-200 (1 to 50 Frames) ***
• Slide Feeder SF-210 (1 to 50 Frames) ***
• Medical Slide Holder FH-G1 ***

Adapters marked with 3 stars (***) are optional adapters not included with this scanner new in box.

Effective Area (Size/Pixel):

• SA-21: 23.3 x 36.0mm (2,567 x 4,104)
• MA-20(S): 25.1 x 36.8mm (2,870 x 4,203)
• FH-3: 24.0 x 36.0mm (2,736 x 4,104)
• IA-20(S): 16.1 x 26.9mm (1,836 x 3,067)
• FH-G1: 22.9 x 35.0mm (2,610 x 3,989)

Illumination method: R, G, B, and D-LED array

Imaging Optics: SCANNER NIKKOR ED lens (7 elements in 4 groups including 3 ED glass elements)

Focusing: Autofocus and Manual focus

Mounted Slides Scanning

Scan time (with ICE):

• Auto focus 1 slide: 5 seconds
• Auto exposure 1 slide: 12 seconds
• Preview 1 slide: 27 seconds
• Preview 1 slide w/ auto focus and auto exposure: 32 seconds
• Single scan slide 2000 dpi: 38 seconds
• Single scan slide 4000 dpi: 54 seconds
• Single scan slide 2000 dpi w/ auto focus and auto exposure: 55 seconds
• Single scan slide 4000 dpi w/ auto focus and auto exposure: 71 minute (1 minute, 11 seconds)

Scan time (without ICE):

• Auto focus 1 slide: 5 seconds
• Auto exposure 1 slide: 12 seconds
• Preview 1 slide: 12 seconds
• Preview 1 slide w/ auto focus and auto exposure: 19 seconds
• Single scan slide 2000 dpi: 21 seconds
• Single scan slide 4000 dpi: 21 seconds
• Single scan slide 2000 dpi w/ auto focus and auto exposure: 36 seconds
• Single scan slide 4000 dpi w/ auto focus and auto exposure: 38 seconds
